EVOLUTION MODULAR COOLING SYSTEM
Universal Modular Radiator System
HZ-40010-X3 22” x 19” HZ-40011-X3 24” x 19” HZ-40012-X3 26” x 19” HZ-40016-X3 31” x 19”
EVOLUTION x3 COOLING SYSTEM
1250 HP RATED
HZ-40010-X2 22” x 19” HZ-40011-X2 24” x 19” HZ-40012-X2 26” x 19” HZ-40016-X2 31” x 19”
EVOLUTION x2 COOLING SYSTEM
850 HP RATED
This is the most extreme modular system available for any application.
The Evolution X3 has a huge 3 ½” thick massive cooling core has three rows of 7/8” high volume and high flow heat transfer tubes with an optimized 15 fins per inch of cooling power.
The Evolution X2 has an oversized 2 1/4” thick cooling core with two rows of 1” high volume and high flow heat transfer tubes with an optimized 15 fins per inch of cooling power. Our engineers have conducted extensive research to determine this is the optimum combination of size and volume for maximum cooling efficiency in extreme applications.
We have further maximized this system with 7 separate AN- 20 bungs allowing the ultimate in universal configuration. We have optional Adapter Fittings for the AN-20 bungs to allow the following attachments:
•HZ-40030-20AN male to 1.25” Radiator Hose Fitting
•HZ-40031-20AN male to 1.75” Radiator Hose Fitting
•HZ-40032-20AN male to 1.50” Radiator Hose Fitting
•HZ-40033-20AN male to -16AN Male Coupling
•HZ-40034-20AN male to 20AN Male Coupling
•HZ-40035-20AN male to ½” NPT Adapter
•HZ-40036-20AN male to 3/8” NPT Adapter
•HZ-40038-20AN male to 2 1/8” Filler Neck
•HZ-40040Radiator Overflow Fitting
•HZ-40037-20AN male Plug
•HZ-40041-20AN O-Ring
